Treluce Light

GRIDIN LT-11.1300

Mesh ceilings are detailed instruments when it comes to lighting. Every milimeters are considered during the design period of Gridin. * BODY: Die-cast aluminium; available in round and square shaped bodies both in two different sizes as well as trimless options. * Fixed body with decorative ring space which allows the light to be seen as ring. * Flush mount installation in false ceilings with 1 to 25 mm thickness; fixing system with steel springs. * Fixture complete with electronic control gear.

Supply: 110-240 V
lllumination Type: Direct
Dimming Protocol:
Not Dimmable
Dimmable on Mains
Dimmable by 1/10 V
Dimmable by DALI
Dimmable by Wireless
Accesories:
Cap W
Honeycomb Louvre HCL
Filterglas
Dichroic Filters
Cap B
Cap G

Lighting Effects

24°

36°

48°

Optic Angle	24°
Optic Angle	36°
Optic Angle	48°
Weight	0,4 kg
Weight	0,62 kg

Code	Power	Lumen	CRI	Color of Light
LT-11.1300-80-27	6,1 W	784 lm	Ra>80	2700 K
LT-11.1300-80-30	6,1 W	817 lm	Ra>80	3000 K
LT-11.1300-80-40	6,1 W	850 lm	Ra>80	4000 K
LT-11.1300-90-27	6,1 W	654 lm	Ra>90	2700 K
LT-11.1300-90-30	6,1 W	681 lm	Ra>90	3000 K
LT-11.1300-90-40	6,1 W	729 lm	Ra>90	4000 K
LT-11.1300-1-80-27	8,9 W	1089 lm	Ra>80	2700 K
LT-11.1300-1-80-30	8,9 W	1134 lm	Ra>80	3000 K
LT-11.1300-1-80-40	8,9 W	1179 lm	Ra>80	4000 K
LT-11.1300-1-90-27	8,9 W	908 lm	Ra>90	2700 K
LT-11.1300-1-90-30	8,9 W	946 lm	Ra>90	3000 K
LT-11.1300-1-90-40	8,9 W	1013 lm	Ra>90	4000 K
LT-11.1300-2-80-27	8,9 W	1089 lm	Ra>80	2700 K
LT-11.1300-2-80-30	8,9 W	1134 lm	Ra>80	3000 K
LT-11.1300-2-80-40	8,9 W	1179 lm	Ra>80	4000 K
LT-11.1300-2-90-27	8,9 W	908 lm	Ra>90	2700 K
LT-11.1300-2-90-30	8,9 W	946 lm	Ra>90	3000 K
LT-11.1300-2-90-40	8,9 W	1013 lm	Ra>90	4000 K
