JOE-LT-11.0111-TR
- "* Recessed trimless square luminaire with rotatable design.
•A lens is used instead of a conventional reflector, it focuses the light beam.
• The mounting trim is installed during rough-in stages of renovations, and the luminaire itself installed during finishing stages.
• BODY: Die-cast aluminium; available in single, double, and triple versions in trimless body.
* Orientable inner body.
• Flush mount installation in false
ceilings with 1 to 25 mm thickness;
fixing system with steel springs. "
-
Supply:
110-240 V
-
lllumination Type:
Direct
-
Dimming Protocol:
Not Dimmable
-
Dimmable on Mains
-
Dimmable by 1/10 V
-
Dimmable by DALI
-
Dimmable by Wireless
-
Accesories:
Cap B
-
Cap G
-
Cap W
-
Honeycomb Louvre HCL
-
Dichroic Filters
-
Filterglas
Code |
Power |
Lumen |
CRI |
Color of Light |
LT-11.0111-TR-27-G |
max. 50 W |
|
|
2700 K |
LT-11.0111-TR-30-G |
max. 50 W |
|
|
3000 K |
LT-11.0111-TR-40-G |
max. 50 W |
|
|
4000 K |
LT-11.0111-TR-80-27 |
6,1 W |
784 lm |
Ra>80 |
2700 K |
LT-11.0111-TR-80-30 |
6,1 W |
817 lm |
Ra>80 |
4000 K |
LT-11.0111-TR-80-40 |
6,1 W |
850 lm |
Ra>80 |
4000 K |
LT-11.0111-TR-90-27 |
6,1 W |
654 lm |
Ra>90 |
2700 K |
LT-11.0111-TR-90-30 |
6,1 W |
681 lm |
Ra>90 |
3000 K |
LT-11.0111-TR-90-40 |
6,1 W |
729 lm |
Ra>90 |
4000 K |
LT-11.0111-1-TR-80-27 |
8,9 W |
1089 lm |
Ra>80 |
2700 K |
LT-11.0111-1-TR-80-30 |
8,9 W |
1134 lm |
Ra>80 |
3000 K |
LT-11.0111-1-TR-80-40 |
8,9 W |
1179 lm |
Ra>80 |
4000 K |
LT-11.0111-1-TR-90-27 |
8,9 W |
908 lm |
Ra>90 |
2700 K |
LT-11.0111-1-TR-90-30 |
8,9 W |
946 lm |
Ra>90 |
3000 K |
LT-11.0111-1-TR-90-40 |
8,9 W |
1013 lm |
Ra>90 |
4000 K |
Color Finish
Grey
Black
White
Dark Grey
